DELHI G Series Double Inlet Belt Drive Blowers With Ball Bearings
The DELHI G Series Double Inlet Belt Drive Blowers with Ball Bearings are built for reliable and efficient performance. Constructed with corrosion-resistant G90 galvanized steel housing, these blowers offer a capacity range of 200 to 8000 CFM. The blower wheel features an exclusive center disc, allowing safe operation at speeds exceeding normal requirements. With extruded holes for secure mounting and matte finish zinc-coated wheels, these blowers ensure quiet, trouble-free operation. Designed with customizable discharge positions and motor mounting hardware, the G Series is perfect for various industrial and commercial applications.
FEATURES
- Capacity range 200 to 8000 CFM
- The blower wheel has an exclusive centre disc which allows blowers to be used safely at speeds well above any normal requirement
- Blower housings have extruded holes to give greater holding power for mounting base sides and motor bracket
- Matte finish zinc coated wheel and cut-off baffle
- Shaft dimensions and finish are carefully controlled to ensure quiet, trouble free operation
- Base feet can be mounted for various discharge positions
- Motor mounting hardware included with each blower
Assembly Service Available
Thank you for your request. Our representative will call you as soon as possible.
| PART NUMBER | SHAFT SIZE | WHEEL DIAMETER | UNIT SIZE (LxWxH) | Vaughan | |
| G7-BB | 3/4" | 8 1/16" | 12.94" x 9.19"x 14.31" |
|
|
| G9-BB | 3/4" | 10 1/4" | 15.06" x 11.81"x 16.94" |
|
|
| G10-BB | 3/4" | 11 9/16" | 16.75" x 13.13"x 19.00" |
|
|
| G12-BB | 1" | 12 7/8" | 19.5" x 15.63"x 22.13" |
|
|
| G15-BB | 1" | 15 1/2" | 22.69" x 18.63"x 25.75" |
|
